More than
a product!
Units
metric
Specifications
Load capacity
290 - 420 kg
290 - 420 kg
Height
50 mm
50 mm
30 mm
Fixation (cabinet side)
Metal: M8
Wood: -
Fixation (drawer side)
Metal: M8
Wood: -
Technical information
Article number
Load capacity
Downloads
13850S01B
200 mm
200 mm
340 kg
13850S02B
250 mm
250 mm
350 kg
13850S03B
300 mm
300 mm
360 kg
13850S04B
350 mm
350 mm
370 kg
13850S05B
400 mm
400 mm
380 kg
13850S06B
450 mm
450 mm
390 kg
13850S07B
500 mm
500 mm
400 kg
13850S08B
550 mm
550 mm
410 kg
13850S09B
600 mm
600 mm
420 kg
13850S10B
650 mm
650 mm
410 kg
13850S11B
700 mm
700 mm
400 kg
13850S12B
750 mm
750 mm
390 kg
13850S13B
800 mm
800 mm
380 kg
13850S14B
850 mm
850 mm
370 kg
13850S15B
900 mm
900 mm
360 kg
13850S16B
950 mm
950 mm
350 kg
13850S17B
1000 mm
1000 mm
340 kg
13850S18B
1050 mm
1050 mm
330 kg
13850S19B
1100 mm
1100 mm
320 kg
13850S20B
1150 mm
1150 mm
310 kg
13850S21B
1200 mm
1200 mm
290 kg
More than a product
fixations
Threaded holes
