Units
metric
Specifications
Load capacity
94 - 129 kg
94 - 129 kg
Height
55.8 mm
55.8 mm
18.5 mm
Fixation (cabinet side)
Metal: M5 / DIN 965 / ISO 7046, M5 / DIN 7500, M5 / DIN 7991 / ISO 10462
Wood: 5.0 / DIN 7997
Fixation (drawer side)
Metal: M4 / DIN 965 / ISO 7046, M4 / DIN 7500, M4 / DIN 7991 / ISO 10462
Wood: 4.0 / 4.5 / DIN 7997
Technical information
Article number
Load capacity
Downloads
112S61F
300 mm
285 mm
94 kg
112S62F
350 mm
350 mm
96 kg
112S63F
400 mm
400 mm
97 kg
112S64F
450 mm
450 mm
110 kg
112S65F
500 mm
500 mm
119 kg
112S66F
550 mm
550 mm
118 kg
112S67F
600 mm
600 mm
123 kg
112S68F
700 mm
700 mm
129 kg
112S69F
800 mm
800 mm
121 kg
More than a product
features
Pull in with fail-safe
fixations
Countersunk holes
fixations
